Breakwire - Breakwire Triggers require a criteria of (0 = Closed) or (1 = Open)

Clock - Clock Trigger criteria refers to the internal Mission Clock of the RRC4, and is expressed as the elapsed time since arming (0.1 sec increments / 0 = Armed)

Boost - This is the Stage Number during a Motor Boost/Burn Phase as defined by the System Inertial Settings (Launch or Staging)

Coast - References the Stage Number of the Coasting Phase (after Motor Boost/Burn), as defined by the System Inertial Settings

Apogee - There are (4) criteria values for Apogee Triggers: (1) = Baro Velocity, (2) = Inertial Velocity, (3) = Baro OR Inertial Velocity, ($) = Baro AND Inertial Velocity

Descent - Applied to the post-apogee phase of a flight as follows: (+Value = AGL ft. / -Value = ft. BELOW Apogee)

Landing - No criteria value required (0), and this event in defined in the System Setup

Custom - Defines which Custom Trigger definition (1 or 2) is applied to this Event trigger.

Cust AND - Applies the AND’d combination of Custom 1 AND Custom 2 Triggers together for the Event trigger.

Cust OR - Applies the OR’d combination of Custom 1 OR Custom 2 Triggers together for the Event trigger.

Breakwire - Breakwire Triggers require a criteria of (0 = Closed) or (1 = Open)

Clock - Clock Trigger criteria refers to the internal Mission Clock of the RRC4, and is expressed as the elapsed time since arming (0.1 sec increments / 0 = Armed)

Boost - This is the Stage Number during a Motor Boost/Burn Phase as defined by the System Inertial Settings (Launch or Staging)

Coast - References the Stage Number of the Coasting Phase (after Motor Boost/Burn), as defined by the System Inertial Settings

Apogee - There are (4) criteria values for Apogee Triggers: (1) = Barometric Velocity, (2) = Inertial Velocity, (3) = Barometric OR Inertial Velocity, (4) = Barometric AND Inertial Velocity

Descent - Applied to the post-apogee phase of a flight as follows: (+Value = AGL ft. / -Value = ft. BELOW Apogee)

Landing - No criteria value required (0), and this event in defined in the System Setup
